48” I.D. x 15’ S/S 1440psi 3 Phase Sour Skidded Well Test Separator Package
48” I.D. x 15’ S/S 1440psi 3 Phase Sour Skidded Well Test Separator Package is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
CONDITION: NEW (Built to Order)
LEAD TIME: 80-90 Days From Order
Size: 48 inch x 15 ft
Design Pressure: 1440 psi
Design Temperature: -29 to 100 C
Service: Sour Service
Corrosion Allowance: 3 mm
Pressure Rating: 600#
Piping material: SA 106 B
Nozzle: SA 105
Vessel: SA 516 Gr.70
ASME B31.3
ASME Sec VIII Div.1
ASME U Stamp
Includes:
Three phase separator with internals;
Steel structures
Other electrical and instrumentation accessories and other components as per technical specification
Package Specification
| Package type | Horizontal 3-Phase Test Separator |
| Application | Well test, oil & gas production, other oilfield operations |
Process Data
| Inlet Flow Range |
Oil Capacity Low Liquid Level: 1,057 m3/d (6,650 bbls/d) one minute retention time Oil Capacity High Liquid Level: 2,289 m3/d (14,400 bbls/d) one minute retention time Gas Capacity Low Liquid Level: 1,699,000 m³/d (40 MM SCFD/d) @ 1,440 psi Gas Capacity High liquid Level: 707,920 m³/d (25 MM SCFD/d) @ 1,440 psi |
| Design Pressure | 1440psig |
| Temperature Rating | -20° to 100° C (-4° to 212° F) |
| Working medium | Oil, Gas, Water |
Vessel Data
| Nominal Vessel Size | 48in X 15ft, Horizontal As per ASME, VIII, Div.1 , U-stamped |
| Corrosion allowance | 3mm |
| Pressure Rating | CL600 |
| Codes & Standards | Pressure Vessel: As per ASME, VIII, Div.1 U-stamped Piping: ASME B31.3 Ball Valves: API 6D |
| Oil Level Control | Level Controller/Transmitter and Pneumatic Control Valve 3” |
| Water Level Control | Level Controller/Transmitter and Pneumatic Control Valve 2” |
| Gas Pressure Control | Pressure Control Valve 3” |
| Water Flow Measurement | Mass Flow Meter 2” |
| Oil Flow Measurement | Mass Flow Meter 3” |
| Gas Flow Measurement | Senior Daniel Orifice Meter 3” |
| Level display | Level Gauges (Sight glasses) |
| Pressure display | Pressure gauges |
| Temperature display | Temperature gauges |
| Safety discharge line | Relief Valve x 2nos, 3” x 4” |
| Sampling | Needle valves for sampling ports |
| Feed Inlet | 3 in., Hammer Union Fig.1502 |
| Gas outlet | 3 in., Hammer Union Fig.200 |
| Oil outlet | 3 in., Hammer Union Fig.200 |
| Water outlet | 2 in., Hammer Union Fig.200 |
